10.8 – 12V Peak Cordless Impact Driver Drill DV12DA

DV12DA 10.8V Cordless Impact Driver Drill

Bit sold separately.

Specifications and others

Easy to Work with

  • Easy to Work with

Runtime per Charge*

  • Approx. 100 Screws in Wood
    (Low Speed + Drill Mode, ø5.8 x 45mm wood screws into American pine with ø4mm pilot holes)
    Approx. 130 Holes in Wood
    (Low Speed + Drill Mode, ø18 x 18mm holes into American pine)
    Approx. 50 Holes in Steel
    (High Speed + Drill Mode, ø6.5 x 1.6mm holes into mild steel)
    Approx. 20 Holes in Mortar
    (High Speed + Impact Drilling Mode, ø3.4 x 30mm holes into mortar)

    • With the BSL 1225M battery. The presented runtimes are shown for reference purposes and may vary according to conditions.
    Runtime per Charge

Other Features

  • 3 Operation Modes (Screw-tightening / Drilling /Impact Drilling)
  • 20-stage Clutch
  • Keyless Chuck
  • LED Light
　　　　　　　　

12V PEAK Slide Lithium-Ion Batteries

  • 14.4Vコードレスインパクトレンチ：WR14DSHL

    4.0Ah / BSL1240M
    High-Capacity

  • 14.4Vコードレスインパクトレンチ：WR14DSHL

    2.5Ah / BSL1225M

  • 18Vコードレスインパクトレンチ：WR18DSHL

    1.5Ah / BSL1215

Lightweight. Compact. High-Capacity.

Clear Battery Status Indication (BSL1240M / BSL1225M only)

  • The remaining battery indicator lamp shows not only charge level but also battery overheating and failure when they occur.

    10.8Vスライド装着イメージ
Indicator Lamp
Solid
Solid
Solid
Solid
Flashing
Battery Charge State 75% and above 50% - below 75% 25% - below 50% Below 25% 0%
Indicator Lamp
Flashing
Flashing
Battery Charge State Output suspended due to high temperature*1 Output suspended due to failure*2
  1. Remove the battery from the tool and allow it to cool down fully.
  2. The problem may be with the battery so please contact your dealer.

Class-leading* Charging Speed

  • Approx. 60min with BSL1240M Battery

    Approx. 37min with BSL1225M Battery

    Approx. 22min with BSL1215 Battery

    Fast Charger

    UC12SL
    Fast Charger

  • As of November 2018, among 10.8V slide Lithium-ion batteries made by leading power tool manufacturers. (Survey by Koki Holdings)

BSL1240M / BSL1225M / BSL1215 12V Peak Slide Lithium-ion Battery

Model BSL1240M BSL1225M BSL1215
Voltage 10.8 - 12V Peak
Capacity 4.0Ah 2.5Ah 1.5Ah
Charging Time at 20℃* Approx. 60min
(with UC12SL)		 Approx. 37min
(with UC12SL)		 Approx. 22min
(with UC12SL)
Dimensions (L x H x W) 91 x 45 x 74mm 86 x 42 x 65mm 86 x 42 x 65mm
Compatible Charger UC12SL
  • The charging time may vary depending on the operating conditions and battery state.

Specifications

Drill Chuck 0.8 - 10mm
Capacity Brick 8mm
Steel 10mm
Wood 29mm
Wood Screw 5.8mm
Machine Screw 6mm
Tightening Torque Hard 38Nm
Soft 15Nm
Torque Setting 0.6 - 4.0Nm
Battery Voltage 10.8 - 12V Peak
No Load Speed High 0 - 1,400/min
Low 0 - 350/min
Impact Rate High 0 - 21,000/min
Low 0 - 5,250/min
Overall Length 181mm
Weight*1 1.2kg(with BSL1225M / BSL1215)
1.3kg(with BSL1240M)
Standard Accessories*2 2 Batteries (BSL1225M), Charger (UC12SL), Battery Cover, Carrying Case
  1. According to EPTA-Procedure 01/2014.
  2. Standard accessories vary by country or area.
PDF： 1,020KB
