MULTI VOLT(36V) Cordless Driver Drill DS36DC

MULTI VOLT
MULTI VOLT(36V) Cordless Driver Drill:DS36DC
  • MV
  • Brushless Motor
  • RFC
Specifications and others

Most Powerful in Industry* & Designed for Continuous Use

* As of December 2022, among 36V cordless driver drills made by leading power tool manufacturers.
(Survey by Koki Holdings)

Drills ⌀36mm Holes Easily

  • Drilling Speed (The speed of DS36DA is indexed as 100.)
    Using a φ36mm auger drill bit to drill through 120mm thick LVL (Laminated Veneer Lumber) with high speed (2) mode.

    Drills φ36mm Holes Easily
    • Vs. the DS36DA cordless driver drill. The value is shown for reference purposes and may vary according to materials and conditions.

Continuously Drives Thick and Long Screws Fast

With an optimally designed motor and an improved inverter circuit, the DS36DC provide the class leading speed even for heavy-duty continuous operations.

Continuous Screw Fastening
Driving M10 x 320mm screws into LVL (with no pilot holes) with low speed (1) mode (with a 20 second interval after driving every two screws)

More than 1.6 times the number of continuous fastening units compared with our conventional products.
  • Vs. the DS36DA cordless driver drill. The value is shown for reference purposes and may vary according to materials and conditions.

Compact Head

  • Compact Head

Side Handle

  • The side handle is adjustable at 11 different positions to suit various applications. The shorter length also makes it easier to handle.

    Side handles 70mm shorter than our conventional products
    New easy to adjust design, Easy to hold anti-slip rubber grip, Firmly locks in place at each angle
    Side handles adjustable at 11 different positions

Reactive Force Control with a Gyro Sensor

A Gyroscope sensor built in the controller measures angular velocity. When its value goes beyond a specified threshold, the motor stops to alleviate the phenomenon that the tool body is swung.

Reactive Force Control with a Gyro Sensor
This feature may not function properly under certain working conditions. Always hold the tool firmly to keep control. If the user suddenly changes position, it can trigger the RFC.

Runtime per Charge*

Work Ah Runtime per Charge
Wood Drilling High Speed Using a φ36mm woodboring auger drill bit to drill through 120mm thick LVL 2.5Ah Approx. 35Holes
  • The values are shown for reference purposes and may vary according to materials and conditions.

Specifications

Battery Voltage 36V
Drill Chuck 1.5 - 13mm Keyless
Capacity Mild Steel 20mm
Soft Wood 118mm
Wood Screw (D x L) 16 x 100mm
Machine Screw 6mm
Max Torque*1 Hard 155Nm
Soft 100Nm
No Load Speed High 0 - 2,200/min
Low 0 - 550/min
Overall Head Length 190mm
Weight*2 2.8kg (with BSL36A18)
3.1kg (with BSL36B18)*3
Standard Accessories*4 2 Batteries (BSL36A18), Charger (UC18YSL3),
Driver Bit, Side Hanldle, Hook, Battery Cover,
Carrying Case
  1. With the BSL36A18 battery.
  2. Weight according to EPTA-Procedure 01/2014.
  3. Sold separately.
  4. Standard accessories vary by country or area.
PDF: 902KB
  • Please contact local dealers for product availability and product details.
